Technical Details
Case type |
Midi-Tower |
max. Motherboard form factor |
E-ATX |
compatible Motherboard form factors |
E-ATX, ATX, Micro-ATX |
Colour |
black |
Primary colour |
black |
Width (exact) |
272 |
Height (exact) |
446 |
Depth (exact) |
445 |
Width |
200 – 300 mm |
Height |
400 – 500 mm |
Depth |
400 – 500 mm |
Weight (exact) |
10.1 |
Weight |
10 to 12 kg (22 to 26.4 lbs) |
Material |
aluminium, steel, Tempered Glass / Hartglas |
max. CPU cooler height (exact) |
155 mm |
max. GPU lenght (exact) |
420 mm |
max. PSU lenght (exact) |
255 mm |
max. CPU cooler height |
140 – 159 mm |
max. GPU lenght |
400 – 500 mm |
max. PSU lenght |
250 – 300 mm |
Side panel |
with window |
Front Door |
Green |
Position I/O |
Seitlich |
USB 3.0 |
2x |
USB 3.1 (Typ C) |
1x |
Audio Out |
|
Audio In |
|
Cardreader |
nein |
Fan controller |
no |
LCD/TFT Display |
nein |
internal 2,5″ |
6x |
internal 3,5″ |
3x |
Hot-Swap |
nein |
PCI-Slots |
8 |
HDD Isolation |
ja |
Motherboard tray |
no |
Case cable management |
yes |
PSU formfactor |
ATX |
PSU position |
rear bottom |
Preinstalled fans |
nein |
120 mm Fans |
9 |
140 mm Fans |
2 |
Radiator Mounting |
1x Dual (280 mm), 2x Triple (360 mm), 2x Dual (240 mm), 1x Single (120 mm) |
Filter |
yes |
Dampening |
no |
Lighting |
yes |
Lighting colour |
RGB (selectable) |
LED compatibility |
Razer Chroma |
Remote control |
nein |
Schlauchdurchführung |
nein |
Serie |
PC-O11D |
Transport System |
nein |
